EMBOSSING
Print Speed: Up to 120 CPS
Printing Mode: Single-sided or double-sided (interpoint)
Tactile Resolution: 100 DPI
Minimum Dot Spacing: 1/17 in
Tactile Graphic Dot Heights: Variable for color representation
Braille Dot Heights: Adjustable in 3 heights
Braille Dot Spacing: Adjustable to 5 international standards
Noise Level: 70 db(A)
Production layout: Single/double sided, portrait or landscape, including Z-fold
Text to Braille on the Fly with Tiger Box (comparable to idB)
PAPER
Paper Width: 7 – 12.5 inches (176 – 317.5 mm)
Paper: Continuous tractor feed
Paper Weight: 33 – 120 lb (90 – 200 gsm)
CONNECTION/COMPATIBILITY
Connection: USB (1.1, 2.0), Ethernet, WIFI/Bluetooth (with Tiger Box)
Compatibility: Current Windows operating systems, Mac OS 10.9+
DIMENSIONS/WEIGHT
Height: 6.2 in (158 mm)
Width: 21.9 in (557 mm)
Depth: 10.8 in (275 mm)
Weight: 19.8 lbs (9 kg)
TEMPERATURE/HUMIDITY
Recommended Temperature: 59 – 95 °F (15 – 35 °C)
Storage Temperature: -4 – 158 °F (-20 – 70 °C)
Humidity: 20 – 80% RH (non-condensing)
POWER SUPPLY
85 – 264 VAC
50/60 Hz (+/- 3%)
Standby: 20 W
Heavy Embossing: 200 W
